Table 41: EIA-530A DCE Cable Pinouts for the 1-Port Serial Mini-PIM
Description
LFH-60
PairingDB-25 PinLFH-60 Pin
Shield Ground-115
Transmit Data (A)221
Receive Data (A)59360
Request to Send (A)38437
Clear to Send (A)47548
Data Set Ready (A)-633
Signal Ground-757
Received Line Signal Detector (A)14813
Receive Clock (B)52951
Received Line Signal Detector (B)131014
Terminal Timing (B)5116
Transmit Clock (B)561255
Clear to Send (B)481347
Transmit Data (B)1142
Transmit Clock (A)551556
Receive Data (B)601659
Receive Clock (A)511752
Local Loopback-1845
Request to Send (B)371938
Data Terminal Ready (A)-209
Signal Ground-234
Terminal Timing (A)6245
---26 to 25
55Copyright © 2017, Juniper Networks, Inc.
Chapter 10: Serial Mini-Physical Interface Module Cable Specifications

Juniper SRX320 Specifications

General

Firewall throughput	1000 Mbit/s
Number of users	50 user(s)
Quality of Service (QoS) support	Yes
Mobile VPN IPSec	250
IPS/IDS throughput	100 Mbit/s
USB 2.0 ports quantity	1
Connectivity technology	Wired
SFP module slots quantity	2
Ethernet LAN (RJ-45) ports	6
Internal memory	4000 MB
Flash memory	8000 MB
Storage media type	Flash
Power consumption (typical)	27 W
Heat dissipation	157 BTU/h
Concurrent connections	64000
Mean time between failures (MTBF)	284700 h
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Routing protocols	BGP, CLNS, IS-IS, OSPF, RIP-1, RIP-2

Weight and Dimensions

Weight	1510 g
Dimensions (WxDxH)	299.9 x 43.9 x 191 mm
