Juniper SRX320 User Manual

Table 45: RS-422/449 DCE Cable Pinouts for the 1-Port Serial
Mini-PIM (continued)
Description
LFH-60
Pairing
DC-37
(DB-37) PinLFH-60 Pin
Terminal Timing (B)5356
Send Common-3757
---26 to 25
Related
Documentation
EIA-530A DCE Cable Pinouts for the 1-Port Serial Mini-Physical Interface Module on
page 54
•
• RS-232 DCE Cable Pinouts for the 1-Port Serial Mini-Physical Interface Module on
page 57
• V.35 DCE Cable Pinouts for the 1-Port Serial Mini-Physical Interface Module on page 63
• X.21 DCE Cable Pinouts for the 1-Port Serial Mini-Physical Interface Module on page 65
RS-422/449 (EIA-449) DTE Cable Pinouts for the 1-Port Serial Mini-Physical Interface
Module
Table 46 on page 61 gives the RS-422/449 DTE cable pinouts.
Table 46: RS-422/449 DTE Cable Pinouts for the 1-Port Serial Mini-PIM
Description
LFH-60
Pairing
DC-37
(DB-37) PinLFH-60 Pin
Shield Ground-115
Send Data (A)59460
Send Timing (A)55556
Receive Data (A)261
Request to Send (A)47748
Receive Timing (A)685
Clear to Send (A)38937
Local Loopback-1041
Data Mode (A)10119
Terminal Ready (A)341233
61Copyright © 2017, Juniper Networks, Inc.
Chapter 10: Serial Mini-Physical Interface Module Cable Specifications

Juniper SRX320 Specifications

General

Firewall throughput	1000 Mbit/s
Number of users	50 user(s)
Quality of Service (QoS) support	Yes
Mobile VPN IPSec	250
IPS/IDS throughput	100 Mbit/s
USB 2.0 ports quantity	1
Connectivity technology	Wired
SFP module slots quantity	2
Ethernet LAN (RJ-45) ports	6
Internal memory	4000 MB
Flash memory	8000 MB
Storage media type	Flash
Power consumption (typical)	27 W
Heat dissipation	157 BTU/h
Concurrent connections	64000
Mean time between failures (MTBF)	284700 h
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Routing protocols	BGP, CLNS, IS-IS, OSPF, RIP-1, RIP-2

Weight and Dimensions

Weight	1510 g
Dimensions (WxDxH)	299.9 x 43.9 x 191 mm
