Table 29: LTE Mini-PIM Front Panel Components
DescriptionComponent
Two SubMiniature version A (SMA) connectors.Antenna connectors
Mini-USB Type-B port for monitoring and troubleshooting.Mini-USB port
Two slots, SIM1 and SIM2, for inserting the SIM cards. The LTE Mini-PIM supports mini, micro,
and nano SIMs. The mini-SIM can be inserted directly in the SIM slot. To insert micro and nano
SIMs, use the SIM adapters supplied with the Mini-PIM. The Mini-PIM is shipped with two SIM
adapters.
SIM slots
Indicate the status at a glance. For details on the LED indications, see “LTE Mini-Physical
Interface Module LEDs” on page 42.
LEDs
The LTE Mini-PIM supports two multi-band swivel-mount dipole antennas, which can
be rotated 360 °. You can rotate the antennas and select the angle at which the signal
strength is high. Table 30 on page 40 lists the specifications for the antenna.
Table 30: Specifications for the LTE Mini-PIM Antenna
ValueSpecification
EDA-2010-4G0R2-A2 (Vendor: MAG.LAYERS)Part number
•
704~960 MHz
•
1710~2700 MHz
Operating frequency range
5 (maximum)Voltage Standing Wave Ratio (VSWR)
50 ohmImpedance
OmnidirectionalRadiation
•
2.45 dBi (704~960 MHz)
•
4.51 dBi (1710~2700 MHz)
Peak gain
1 WInput power
Linear, verticalPolarization
–4° F (–20° C) to 149° F (65° C)Operating temperature
SMAConnector type
203 mmLength
The antenna is connected to the services gateway through the magnetic antenna base.
Table 31 on page 41 lists the specifications for the antenna base.
Copyright © 2017, Juniper Networks, Inc.40
SRX300 Series and SRX550 High Memory Gateway Interface Modules Reference
