Juniper SRX320 User Manual

SRX300 Series and SRX550 High Memory Services Gateway Interfaces Power and
Heat Requirements
Table 12 on page 12 shows the power consumption values of each Physical Interface
Module (PIM).
Table 12: PIM Power Consumption Values
Power Consumption (Watts)PIM Model
4.29Serial Mini-PIM
1.92T1/E1 Mini-PIM
9.80VDSL2 Mini-PIM
228-Port Gigabit Ethernet SFP XPIM
40 (without PoE)16-Port Gigabit Ethernet XPIM
4.8LTE Mini-PIM
Related
Documentation
• MTU Default and Maximum Values for Physical Interface Modules on page 8
• Power over Ethernet Support on SRX550 High Memory Services Gateway Interfaces
on page 10
Copyright © 2017, Juniper Networks, Inc.12
SRX300 Series and SRX550 High Memory Gateway Interface Modules Reference

Juniper SRX320 Specifications

General

Firewall throughput	1000 Mbit/s
Number of users	50 user(s)
Quality of Service (QoS) support	Yes
Mobile VPN IPSec	250
IPS/IDS throughput	100 Mbit/s
USB 2.0 ports quantity	1
Connectivity technology	Wired
SFP module slots quantity	2
Ethernet LAN (RJ-45) ports	6
Internal memory	4000 MB
Flash memory	8000 MB
Storage media type	Flash
Power consumption (typical)	27 W
Heat dissipation	157 BTU/h
Concurrent connections	64000
Mean time between failures (MTBF)	284700 h
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Routing protocols	BGP, CLNS, IS-IS, OSPF, RIP-1, RIP-2

Weight and Dimensions

Weight	1510 g
Dimensions (WxDxH)	299.9 x 43.9 x 191 mm
