Table 45: RS-422/449 DCE Cable Pinouts for the 1-Port Serial Mini-PIM
Description
LFH-60
Pairing
DC-37
(DB-37) PinLFH-60 Pin
Shield Ground-115
Send Data (A)241
Send Timing (A)55556
Receive Data (A)59660
Request to Send (A)38737
Receive Timing (A)51852
Clear to Send (A)47948
Local Loopback-1045
Data Mode (A)341133
Terminal Ready (A)10129
Receive Ready (A)141313
Terminal Timing (A)6175
Signal Ground-1936
Receive Common-204
Send Data (B)1222
Send Timing (B)562355
Receive Data (B)602459
Request to Send (B)372538
Receive Timing (B)522651
Clear to Send (B)482747
Data Mode (B)332934
Terminal Ready (B)93010
Receiver Ready (B)133114
Copyright © 2017, Juniper Networks, Inc.60
SRX300 Series and SRX550 High Memory Gateway Interface Modules Reference

Juniper SRX320 Specifications

General

Firewall throughput	1000 Mbit/s
Number of users	50 user(s)
Quality of Service (QoS) support	Yes
Mobile VPN IPSec	250
IPS/IDS throughput	100 Mbit/s
USB 2.0 ports quantity	1
Connectivity technology	Wired
SFP module slots quantity	2
Ethernet LAN (RJ-45) ports	6
Internal memory	4000 MB
Flash memory	8000 MB
Storage media type	Flash
Power consumption (typical)	27 W
Heat dissipation	157 BTU/h
Concurrent connections	64000
Mean time between failures (MTBF)	284700 h
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Routing protocols	BGP, CLNS, IS-IS, OSPF, RIP-1, RIP-2

Weight and Dimensions

Weight	1510 g
Dimensions (WxDxH)	299.9 x 43.9 x 191 mm
