KARCHER Surface Cleaner 9.802-898.0
15
PRESSURE WASHER
OPERATOR’S MANUAL
EXPLODED VIEW PARTS LIST (SCW-4.0/40 GL)
ITEM PART NO. DESCRIPTION QTY
1 8.758-208.0 Gasoline Engine Black Loncin G420FA 1
2 9.802-817.0 Washer, 3/8" X 1" 6
3 9.802-816.0 Washer, 7/16", Split Ring Lock, 780481 2
4 6.390-126.0 Clamp Hose 1
5 9.802-744.0 Bolt, 10mm X 20mm, Hh Zinc 2
6 9.802-722.0 Bolt, 3/8 X 1-1/4", Nc Hh 5
7 9.802-254.0 Hose, 1/4" Push-On, /Ft 9"
8 9.802-154.0 Plug, Push-On,Oil Drain, Honda 1
9 9.802-153.0 Swivel, 1/4" Jic Fem, Push-On 1
10 9.802-125.0 Plug, 1/4" Jic 1
11 9.802-066.0 Pad Soft Rubber 1
12 9.198-004.0 3/8 Uss F/W Zinc 2
13 9.197-003.0 3/8-16 Ne Nylon Insert L/N Zc 5um White 1
14 9.196-041.0 Hex Head Bolt 3/8-16 X 1-3/4 4
15 8.930-003.0 Pump Support Jarvis 2.0 Painted 1
16 8.930-001.0 Canister Holder Jarvis 2.0 Painted 1
17 8.929-851.0 Pump Assembly Surface Cleaner 2.0 1
18 8.929-359.0 Bracket Clamp 1
19 9.802-809.0 Washer, 1/2" Flat Sae 3
20 9.802-164.0 Coupler, 1/4"Socket, Female, Brass 1
21 9.182-506.0 Cap Black Plastic,5/8''Fastener 2
22 8.929-859.0 Hose 1/4"X 45.250" 2WIRE 6000PSI 1
23 8.929-838.0 Frame Surface Cleaner 2.0 painted 1
24 8.759-392.0 Ball Caster 4"X1.25 1/2-13UNC With Lock 1
25 8.759-391.0 Surface Cleaner 28" 1
26 8.757-802.0 Grip bar 1.25"x 7.00" Vynil 1
27 8.757-776.0 Hose Hanger Cap 3/8"x 5 1/2" 1
28 8.757-339.0 Elbow, 1/4" Street 90 Deg, Steel W/Slnt 2
29 8.756-365.0 Qh Wheel Assy 10",Gray Stl Rim, Flat 2
30 8.755-010.0 Rivnut, Rib Flg Hd, 1/4"-20 8
31 8.751-374.0 Spacer 5/8 X 1,25 Black 4
32 9.802-752.0 Screw, 1/4" X 1-1/4", Whiz Loc Flange 8
33 8.718-941.0 Screw, 10-16 X 5/8 Tek 1
34 8.718-829.0 Nut, 1/2", Esna 1
35 8.709-090.0 Clamp, Wire/Tube, 0.750D 1
36 8.930-854.0 Reinforcing Plate surface cleaner 2
37 8.930-855.0 Reinforcing Plate bottom surface cleaner 2
38 8.750-776.0 Clip, 1.000 ID RND 2
39 9.802-802.0 Washer, 1/4" Flat Sae Zinc 2
To Next Page
