KARCHER Surface Cleaner 9.802-898.0
99
MACHINE À LAVER À HAUTE PRESSION
MANUEL DE L'UTILISATEURL
LISTE DES PIÈCES SCW 2.4/25 G & SCW 2.4/25 GL
ART. RÉF. DESCRIPTION QTÉ
1 9.802-317.0 Engine, Honda, GX200UT2QX2 1
2 8.929-258.0 Pump KARCHER KPP2535G, 2.5@3500, 3400RPM 1
3 8.754-696.0 Unloader, VBT Banjo 1/2M 3/8M, 3000PSI 1
4 8.756-365.0 QH Wheel Assy 10",gray STL RIM, Flat 2
5 8.749-545.0 Caster,4"X1.25,1/2-13&TM,W/O Lock 1
6 8.925-431.0 Base, Surface Cleaner_Painted 1
7 8.750-844.0 Holder, Wand 1
8 8.925-437.0 Wand Holder Bracket, Painted 1
9 8.757-180.0 Shroud Assy, 21" Surface Cleaner 1
10 8.750-768.0 Screw, 1/4-20 x 1", Whiz Loc Flange 8
11 9.802-713.0 Bolt, 5/16" x 1-1/2", NC HH(612975) 4
12 8.718-980.0 Washer, 5/16" at, SAE (780452) 8
13 9.802-776.0 Nut, 5/16-18, ESNA 4
14 8.706-200.0 Elbow, 1/4"""", Street-P/N-TF3409X4 2
15 9.802-809.0 Washer, 1/2" Flat SAE 2
16 8.718-829.0 Nut, 1/2", ESNA 1
17 9.182-506.0 Cap Black Plastic,5/8''Fastener 2
18 9.802-810.0 Washer 5/8"""" 4
19 9.802-813.0 Washer, 5/16" Split Ring Lock, Zinc 4
20 8.733-007.0 Socket Head 5/16-24 X ¾ Zinc Plated 4
21 9.802-146.0 Swivel, 1/2" MP X 3/4" GHF W/Strainer 1
22 8.706-167.0 Elbow, 3/8" FPT, 90 DGR, P/N-TF3509X6 1
23 8.925-467.0 Hose,1/4" X 10",R2, Pressure LO 1
24 8.925-466.0 Hose,1/4" X 26",R2, Pressure LO 1
25 8.918-187.0 Hose,1/4" X 42", 2 Wire, Guage Hose 1
26 8.706-829.0 Elbow, 1/2" Street, Brass 1
27 8.757-353.0 Label, Karcher Signet 1
28 8.900-222.0 Label, Waterjet Warning 1
29 8.709-090.0 Clamp, Wire/Tube, 0.750D 1
30 8.757-403.0 Label, Warning Trilingual 1
31 9.802-802.0 Washer, 1/4" Flat SAE Zinc 1
32 8.706-865.0 Plug, 1/4" NPT COUNTERSUNK 1
33 8.707-256.0 Pump Protector,1/2" PTP,140DEG,P/N 1005 1
34 8.757-499.0 Hose Barb 10-1.25 X 1/4" Pipe 1
35 8.706-321.0 Cap, Pipe, 1/8'NPT Brass 1
36 9.802-254.0 Hose, 1/4" Push-ON, /FT 0.500
37 8.706-940.0 Hose Barb, 1/4"" Barb X 1/8"" ML PIPE" 1
38 6.390-126.0 Clamp Hose 2
39 9.802-958.0 Key, 0.185 SQR X 1.75' 1
40 8.706-865.0 Plug, 1/4" NPT Countersunk 1
41 8.706-297.0 Bushing, 3/8" x 1/4" Steel Yellow Chrom 1
42 8.706-233.0 Tee, 1/4" Street, Steel 1
43 8.707-139.0 Coupler, 1/4"Plug, Male, Steel/Zinc 1
44 9.802-164.0 Coupler, 1/4" Socket, Female, Brass 1
45 8.718-941.0 Screw, 10-16 X 5/8 TEK 1
47 8.600-562.0 Nut, 1/4-20 Well 1
48 9.802-754.0 Screw, 1/4" x 1/2" NC, Whiz LOC Flange 1
