Maintenance Wiper blades
Replacing rear wiper blade
Move the rear wiper to the bottom mid
-
dle part, and lift up the wiper arm. Pull
the wiper blade to remove it.
1. Within 20 seconds after the vehicle
ignition is OFF, move the wiper lever
to MIST/1x position for over 2 seconds
until the wiper moves down to the
bottom middle part.
2. Raise the wiper arm and pull out the
wiper blade assembly.
3. Lift up the wiper blade, and pull the
blade to remove it.
4. Install the new blade assembly by
inserting the centre part into the slot
in the wiper arm until it clicks into
place.
If the replacement is complete, put
down the wiper arm to place it on the
rear windscreen, and turn the vehicle
ignition to ON and operate the wipers
to check the blade is installed cor
-
rectly.
