Maintenance Fuses
5. Push in a new fuse of the same rating,
and make sure it fits tightly in the
clips.
If it fits loosely, consult a professional
workshop. Kia recommends to consult
an authorised Kia dealer/service partner.
If you do not have a spare, use a fuse of
the same rating from a circuit you may
not need for operating the vehicle, such
as the cigarette lighter fuse.
If the headlights or taillights, stoplights,
courtesy lamp, day time running lights
(DRL) do not work and the fuses are OK,
consult a professional workshop. Kia
recommends to consult an authorised
Kia dealer/service partner.
Engine compartment fuse
replacement
1. Turn the ignition switch or ENGINE
START/STOP button and all other
switches off.
2. Remove the fuse panel cover by
pressing the tab and pulling the cover
up.
When the blade type fuse is discon
-
nected, remove it by using the clip
designed for changing fuses located
in the engine room fuse box. Upon
removal, securely insert reserve fuse
of equal quantity.
3. Check the removed fuse; replace it if
it is blown. To remove or insert the
fuse, use the fuse puller in the engine
compartment fuse panel.
4. Push in a new fuse of the same rating,
and make sure it fits tightly in the
clips. If it fits loosely, consult a profes
-
sional workshop. Kia recommends to
consult an authorised Kia dealer/ser
-
vice partner.
After checking the fuse panel in the
engine compartment, securely install the
fuse panel cover through the audible
clicking sound.
If not, electrical failures may occur from
water contact.
Main fuse (Multi fuse)
If the main fuse is blown, it must be
removed as follows:
1. Turn off the engine.
2. Disconnect the negative battery cable.
3. Remove the nuts shown in the picture
above.
4. Replace the fuse with a new one of
the same rating.
5. Reinstall in the reverse order of
removal.
