OPERATING THE TRACTOR 7-7
196O712A196O711A
(1) Brake Pedal Lock
(A) Lock (B) RELEASE
CK20H
CHECKING THE BRAKE PEDAL
1. Before operating the tractor on the
road or before applying the parking
brake, be sure to interlock the right
and left pedals as illustrated below.
2. Use individual brakes to assist in mak-
ing sharp turns at slow speeds (Field
Operation Only).
Disengage the brake pedal lock and
depress only one brake pedal.
3. Be sure brake pedals have equal ad-
justment when using locked together.
BRAKE PEDAL (RIGHT AND LEFT)
WARNING
To avoid personal injury:
Applying one rear wheel brake at
a time can cause the tractor to
swerve or roll over at high speeds.
(1) Brake Pedal Lock
(A) Lock (B) RELEASE
CK20
To Next Page
