7-10 CK20
MAIN GEAR SHIFT LEVER
The main shift uses a syncro-mesh and
a constant mesh.
Rotary power which is transmitted from
engine to gear shaft via the clutch is
changed in three ways by operating the
main shift lever to shift the shifters, and
transmits to the counter shaft.
RANGE GEAR SHIFT LEVER (HI-LO)
The range gear shift can only be shifted
when tractor is completely stopped and
clutch is depressed.
If it is difficult to shift the range gear,
take the following actions.
1. Be sure the range gear shift lever is in
neutral position.
2. Release clutch pedal.
3. Slightly depress the speed control
pedal to rotate the gears inside of
transmission.
4. Release the speed control pedal to
neutral.
5. Depress clutch pedal and then shift
the range gear shift lever.
IMPORTANT
To avoid transmission damage,
depress clutch pedal and stop
tractor before shifting between
ranges.
