PERIODIC SERVICE 12-7
1. Check front grill and side screens to
be sure they are clean of debris.
2. Detach the screen and remove all the
foreign material.
1. Inspect the instrument panel for bro-
ken gauge(s), meter(s) and Easy
Checker lamps.
2. Replace if broken.
CHECKING HEAD LIGHT,
HAZARD LIGHT ETC.
1. Inspect the lights for broken bulbs and
lenses.
2. Replace if broken.
CHECKING SEAT BELT AND ROPS
1. Always check condition of seat belt
and ROPS attaching hardware before
operating tractor.
2. Replace if damaged.
CHECKING GAUGES, METER AND
EASY CHECKER
CAUTION
To avoid personal injury:
Be sure to stop the engine be-
fore removing the screen.
IMPORTANT
Grill and screen must be clean
from debris to prevent engine
from overheating and to allow
good air intake for the air cleaner.
196OC10A
196OC09A
(1) Radiator Screen (A) DETACH (2) Oil Cooler Screen
CK20H
CLEANING GRILL, RADIATOR SCREEN
AND OIL COOLER SCREEN
CK20
To Next Page
