Kioti CK20 - MID-P.T.O. Lever; MID-P.T.O. Shaft Cover; Rear and MID -P.T.O. Speed

7-24 CK20
196O733A196O732A
(1) Mid P.T.O (3) P.T.O Shaft Cover
(2) Bolt
(1) P.T.O Gear Shift Lever
(2) Mid-P.T.O Lever
MID-
P.T.O
lever
P.T.O Gear Sift Lever/
P.T.O Clutch control lever
REAR AND MID-P.T.O SPEED
P.T.O
Rear
Mid
Rear
Mid
P.T.O REVOLUTION [mn
-1
(rpm)]
0
0
0
0
540
0
540
2,000
MID-P.T.O LEVER MID-P.T.O SHAFT COVER
The mid P.T.O is available for KIOTI ap-
proved implements.
MID-P.T.O
To use mid-P.T.O, shift the P.T.O gear shift
lever and mid-P.T.O lever to engaged
position. This shifting requires clutch pedal
operation.
WARNING
To avoid personal injury:
zz
zz
z
Before operation, be sure to se-
lect the correct P.T.O lever (mid /
rear).
zz
zz
z
Do not operate rear-P.T.O driven
implements and mid-P.T.O driven
implements at the same time.
