Preparation for Use
2
bizhub PRO C6501 2-15
No. Name Description
1 Secondary (Sub) tray Holds sets output in Non-sort mode.
2 Top cover handle (left) Opens to remove mishandled paper.
3 Top cover handle (right) Opens to remove mishandled paper.
4 Paper removal indicator Lights while the stacker goes down in order to allow
takeout of printed sheets.
5 Paper removal button Pressed to take out printed sheets from the stacker.
6 Large capacity stacker door Opens to take out printed sheets from the stacker.
7 Outlet cover lever Opens to remove mishandled paper.
8 Secondary (Sub) tray convey-
ance cover handle
Opens to remove mishandled paper.
9 Stacker conveyance knob Can be turned clockwise to feed mishandled paper to the
stacker.
10 Secondary (Sub) tray convey-
ance knob
Can be turned clockwise to feed mishandled paper to the
secondary (sub) tray.
11 Outlet knob Can be turned clockwise to feed mishandled paper to the
outlet.
12 Inlet lever Opens downward to remove mishandled paper.
13 Stacker Holds sets output in Non-sort mode or Collate mode (off-
set).
14 Outlet lever Opens downward to remove mishandled paper.
15 Carriage Carries paper together with the stacker.
16 Paper holder Mounts paper stopper for holding output paper.
17 Paper stopper Holds output paper.
To Next Page
