Preparation for Use
2
bizhub PRO C6501 2-17
External View
Internal View
No. Name Description
1 Secondary (Sub) tray of Sad-
dle stitcher
Holds non-sorted sets output from Saddle stitcher.
2 Multi tri-folding mode outlet
cover handle
Opens upward to remove mishandled paper.
3 Multi tri-folding mode tray Holds sets output in multi tri-folding mode.
4 Secondary (Sub) tray Holds non-sorted sets output from the machine on the
right side of the Saddle stitcher.
5 Right side door of Saddle
stitcher
Opens to remove mishandled paper.
6 Saddle stitcher tray Withdrawn when using Fold & Staple and multi half fold-
ing mode.
7 Waste basket Withdrawn to remove waste paper.
8 Left side door of Saddle
stitcher
Opens for staple supply or to remove mishandled paper.
No. Name Description
1 Upper cover lever of Folding
unit
Opens the upper cover to remove paper misfed inside the
Folding unit.
2 Secondary (Sub) tray convey-
ance lever (middle)
Opens downward to remove mishandled paper.
3 Folding unit drawer handle Opens the drawer to remove paper misfed inside the
Folding unit.
4 Secondary (Sub) tray convey-
ance lever (right)
Opens upward to remove mishandled paper.
5 Inlet lever Opens leftward to remove mishandled paper.
6 Feeding knob Can be turned clockwise to feed mishandled paper to the
Folding unit.
7 Folding unit conveyance lever Opens rightward to remove mishandled paper.
8 Folding unit conveyance cov-
er handle
Opens the cover to remove mishandled paper.
9 Folding unit front cover lever Opens upward to remove mishandled paper.
10 Stapling unit Staples folded sets.
11 Stapling unit knob Can be turned clockwise to feed mishandled paper.
12 Outlet lever Opens leftward to remove mishandled paper.
13 Outlet conveyance lever Opens downward to remove mishandled paper.
To Next Page
