8.9 Oil level check and oil change on the cutter bar
Pos: 20.31.2 /B A/Sicherheit/Ge fahrenhinweise /Mähwerke/Sc hnell rotierend e Messerteller/M essertrommel n_1 @ 0\mod _1197017696 736_78.doc @ 1 6001
Danger! - Rapidly rotating cutting discs/blade drums.
Effect: Danger to life or serious injuries.
• Switch off the engine and remove the ignition key.
• The cutting discs/blade drums continue to run!
• Do not leave the driver’s cab until the cutting discs/blade drums have come to a complete
stop.
Pos: 20.31.3 /Üb erschriften/Üb erschriften 3/K-O/M ähholm ausric hten @ 0\m od_11970179 56815_78.doc @ 16042
8.9.1 Aligning the Cutter Bar
Pos: 20.31.4 /B A/Wartung/Mäh werke/Mähhol m ausrichten Eas yCut @ 3\mod _1204721803 648_78.doc @ 72358
EC-0-001
Fig. 19
Oil level check
• Align the cutter bar using a spirit level (1).
Crosswise
• Lay the spirit level on top of the cutting disc hub parallel to the direction of travel.
Lengthwise
• Lay the spirit level (1) on top of two mower discs.
