WHEELS, TIRES 107
12.3Removing rear wheel x
– Raise the motorcycle with the lift stand. ( p. 65)
100267-10
– Press the brake caliper by hand on to the brake disc in order to press back the brake
piston.
– Remove nut . Remove chain adjuster .
– Holding the rear wheel, withdraw the wheel spindle .
100268-01
– Push the rear wheel forwards as far as possible and take the chain off the rear sprocket.
Warning
Danger of accidents Reduced braking efficiency caused by damaged brake
discs.
– Always lay the wheel down in such a way that the brake disc is not damaged.
– Take the rear wheel out of the swing arm.
Info
Do not operate the foot brake when the rear wheel is removed.
