TECHNICAL DATA - CHASSIS TIGHTENING TORQUES 173

Screw, license plate holder, bottom EJOT 3 Nm (2.2 lbf ft) –

Screw, side stand switch EJOT 2 Nm (1.5 lbf ft) –

Screw, SLS valve EJOT 2 Nm (1.5 lbf ft) –

Spoke nipple, front wheel M4.5 4 Nm (3 lbf ft) –

Bolt, foot brake lever stub M5 6 Nm (4.4 lbf ft)

Loctite

243™

Remaining screws, chassis M5 5 Nm (3.7 lbf ft) –

Screw, electrical holder M5 3 Nm (2.2 lbf ft) –

Screw, exhaust heat shield M5 6 Nm (4.4 lbf ft)

Loctite

243™

Screw, fuel level sensor M5 3 Nm (2.2 lbf ft) –

Screw, fuel pump M5 6 Nm (4.4 lbf ft) –

Screw, headlight mask M5 5 Nm (3.7 lbf ft) –

Screw, starter cable on starter M5 3 Nm (2.2 lbf ft) –

Spoke nipple, rear wheel M5 4 Nm (3 lbf ft) –

Nut, foot brake cylinder screw M6 10 Nm (7.4 lbf ft) –

Remaining nuts, chassis M6 15 Nm (11.1 lbf ft) –

Remaining screws on fuel tank M6 5 Nm (3.7 lbf ft) –

Remaining screws, chassis M6 10 Nm (7.4 lbf ft) –

Screw, air filter box top M6 2 Nm (1.5 lbf ft) –

Screw, ball joint of push rod on foot

brake cylinder

M6 10 Nm (7.4 lbf ft)

Loctite

243™

Screw, brake fluid reservoir of rear brake M6 5 Nm (3.7 lbf ft) –

Screw, chain sliding guard M6 6 Nm (4.4 lbf ft)

Loctite

243™

Screw, front brake disc M6 14 Nm (10.3 lbf ft)

Loctite

243™

Screw, ignition lock M6 10 Nm (7.4 lbf ft)

Loctite

243™

Screw, lower radiator bracket M6 8 Nm (5.9 lbf ft) –
