TECHNICAL DATA - CHASSIS 168
Secondary drive ratio 15:45
Chain 5/8 x 1/4” X‑ring
Steering head angle 63°
Wheelbase 1,504±15 mm (59.21±0.59 in)
Seat height unloaded 930 mm (36.61 in)
Ground clearance unloaded 320 mm (12.6 in)
Weight without fuel approx. 138.5 kg (305.3 lb.)
Maximum permissible front axle load 150 kg (331 lb.)
Maximum permissible rear axle load 200 kg (441 lb.)
Maximum permissible overall weight 350 kg (772 lb.)
Battery YTZ10S Battery voltage: 12 V
Nominal capacity: 8.6 Ah
maintenance-free
Fuse 58011109130 30 A
Fuse 75011088015 15 A
Fuse 75011088010 10 A
23.1Lighting equipment
Headlight S2 / socket BA20d 12 V
30/35 W
Parking light W5W / socket W2.1x9.5d 12 V
5 W
Instrument lights and indicator lamps LED
Turn signal R10W / socket BA15s 12 V
10 W
