CONTROLS 30
5.21Combination instrument - TRIP F display
800083-21
If the fuel level drops to the reserve mark, the display automatically changes to Trip F and
starts to count from 0.0, regardless of the previous display mode.
Info
Parallel to the Trip F display, the fuel warning light switches on.
5.22Combination instrument - coolant temperature indicator
800085-10
The temperature display consists of 8 bars. The more bars that light up, the hotter the
coolant. When the upper bar lights up, all bars in the display begin to flash and the tem-
perature warning lamp lights up.
Possible states
• Engine cold – No bars light up.
• Engine warm – Four bars light up.
• Engine hot – All eight bars flash.
