WHEELS, TIRES 110
100271-10
– Check bearing .
» If the bearing is damaged or worn:
–
Replace the bearings. x
– Check rubber dampers of the rear hub for damage and wear.
» If the rubber dampers of the rear hub are damaged or worn:
– Change all rubber dampers in the rear hub.
100272-10
– Lay the rear wheel on a workbench with the rear sprocket facing upwards and insert the
wheel spindle in the hub.
– To check play , hold the rear wheel tight and try to rotate the rear sprocket.
Info
Measure the play on the outside of the rear sprocket.
Play in rubber dampers, rear wheel ≤ 5 mm (≤ 0.2 in)
» If play is larger than the specified value:
– Change all rubber dampers in the rear hub.
–
Install the rear wheel. x ( p. 108)
12.6Checking the tire condition
Warning
Danger of accidents Uncontrollable vehicle handling in the event of a flat tire.
– In the interest of safety, replace damaged or worn tires immediately. (Your authorized KTM workshop will be glad to help.)
