SERVICE WORK ON THE CHASSIS 85
100281-10
– Remove screws .
– Remove cover with membrane .
– Check the fluid level.
Fluid level under top level of container 4 mm (0.16 in)
» If the level of the coolant does not meet specifications:
– Correct the fluid level of the hydraulic clutch.
Hydraulic fluid (15) ( p. 178)
– Position the cover with the membrane. Mount and tighten the screws.
10.21Removing the engine guard
– Stand the motorcycle on its side stand on a horizontal surface.
100198-10
– Remove screws on the left and right.
– Pull the engine guard forward out of the holders and set it down.
