TUNING THE ENGINE 138
15.2Adjusting the play in the throttle cable x
100280-10
– Move the handlebar to the straight-ahead position.
– Use the KTM diagnostics tool to set the motor drive to the basic position.
– Loosen counter nut .
– Set the play in the throttle cable by turning the adjusting screw .
Guideline
Throttle cable play 3… 5 mm (0.12… 0.2 in)
– Tighten counter nut .
15.3Adjusting the engine characteristic
– Switch off the ignition by turning the ignition key to position OFF .
– Remove the seat. ( p. 70)
100237-10
– Pull the Map‑Select switch and holder upward off of the retaining bracket.
– Pull the Map‑Select switch out of the holder.
