6 CONTROLS 16
6.17 Foot brake lever
B01024-10
Foot brake lever 1 is located in front of the right footrest.
The foot brake lever is used to activate the rear brake.
6.18 Side stand
B01666-10
The side stand 1 is on the left side of the vehicle.
B01667-10
The side stand is used to park the motorcycle.
Info
When you are riding, side stand 1 must be folded up and secured with rubber
band 2.
6.19 Steering lock
B01668-10
Steering lock 1 is fitted on the left side of the steering head.
The steering lock is used to lock the steering. Steering, and therefore riding, is no
longer possible.
6.20 Locking the steering
Note
Danger of damage The parked vehicle may roll away or fall over.
– Always place the vehicle on a firm and even surface.
