12 SERVICE WORK ON THE CHASSIS 45
12.17 Installing the front fender
B01030-10
– Ensure that the spacers are mounted in the fender.
– Position the front fender. Mount and tighten screws 1.
Guideline
Remaining screws, chassis M6 10 Nm (7.4 lbf ft)
Info
Make sure the holding lugs engage in the headlight mask.
12.18 Folding the seat up
B01021-10
– Press release lever 1.
– Lift the seat and fold it up.
12.19 Locking the seat
B01022-10
– Fold down the seat and push it down.
The seat engages with an audible click.
– Finally, check that the seat is correctly locked.
12.20 Removing the air filter housing x
Note
Engine failure Unfiltered intake air has a negative effect on the service life of the engine.
– Never ride the vehicle without an air filter since dust and dirt can get into the engine and result in increased wear.
Preparatory work
– Fold the seat up. ( p. 45)
