7 SPEEDOMETER 18
7.1 Overview
401908-10
1 Overview of indicator lamps ( p. 14)
2 Left button
3 Display
4 Right button
7.2 Activation
401908-01
Activating the speedometer
The speedometer is activated when one of the buttons is pressed or an impulse comes
from the wheel speed sensor.
7.3 Message on the speedometer
401901-01
Possible states
Battery voltage of the speedometer – Battery voltage of the speedometer
is too low. Change the battery.
Service – A service is due. Contact an authorized KTM workshop.
7.4 Setting the speedometer
Condition
The motorcycle is stationary.
401909-01
– Press both buttons for 3–5 seconds.
The Setup menu is displayed. The UNIT display flashes.
– Press one of the buttons to select UNIT for the speed in kilometers KM/H or miles
M/H.
401911-01
– Wait for 5 seconds.
The speedometer changes to the next menu item. The symbol flashes.
– Press one of the buttons to select the 24h or 12h display of the clock.
