22 TECHNICAL DATA 97
Air chamber length 120
+10
−40
mm (4.72
+0.39
−1.57
in)
Fork oil per fork leg 390 ml (13.19 fl. oz.) Fork oil (SAE 4) (48601166S1) ( p. 100)
22.8 Shock absorber
Shock absorber part number 15.18.7N.42
Shock absorber WP Suspension 4618 BAVP DCC
Compression damping, low-speed
Comfort 20 clicks
Standard 15 clicks
Sport 10 clicks
Compression damping, high-speed
Comfort 2.5 turns
Standard 2 turns
Sport 1 turn
Rebound damping
Comfort 20 clicks
Standard 15 clicks
Sport 10 clicks
Spring preload
Comfort 8 mm (0.31 in)
Standard 8 mm (0.31 in)
Sport 8 mm (0.31 in)
Spring designation
Weight of rider: 65… 75 kg (143… 165 lb.) (61/59) 55-215
Weight of rider: 75… 85 kg (165… 187 lb.) (61/59) 55/63/71-215
Weight of rider: 85… 95 kg (187… 209 lb.) (61/59) 58/62/74-215
Spring length 215 mm (8.46 in)
Gas pressure 10 bar (145 psi)
Static sag 15 mm (0.59 in)
Riding sag 80 mm (3.15 in)
Fitted length 367 mm (14.45 in)
Shock absorber oil Shock absorber oil (SAE 2.5) (50180342S1) ( p. 101)
22.9 Chassis tightening torques
Spoke nipple M4.5 5… 6 Nm (3.7… 4.4 lbf ft) –
Screw, battery terminal M5 2.5 Nm (1.84 lbf ft) –
Screw, shock absorber adjusting ring M5 5 Nm (3.7 lbf ft) –
Nut, cable on starter motor M6 4 Nm (3 lbf ft) –
Remaining nuts, chassis M6 10 Nm (7.4 lbf ft) –
Remaining screws, chassis M6 10 Nm (7.4 lbf ft) –
Screw, ball joint of push rod on foot
brake cylinder
M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, front brake disc M6 14 Nm (10.3 lbf ft)
Loctite
®
243™
Screw, radiator bracket M6 7 Nm (5.2 lbf ft) –
Screw, rear brake disc M6 14 Nm (10.3 lbf ft)
Loctite
®
243™
Screws, throttle grip M6 3 Nm (2.2 lbf ft) –
Nut, foot brake lever stop M8 20 Nm (14.8 lbf ft) –
Nut, rear sprocket screw M8 35 Nm (25.8 lbf ft)
Loctite
®
243™
Nut, rim lock M8 10 Nm (7.4 lbf ft) –
Remaining nuts, chassis M8 25 Nm (18.4 lbf ft) –
Remaining screws, chassis M8 25 Nm (18.4 lbf ft) –
