23 TECHNICAL DATA 120

Shock absorber oil Shock absorber fluid(SAE 2.5)(50180751S1) ( p. 121)

23.9 Chassis tightening torques

Spoke nipple M4.5 5 Nm (3.7 lbf ft) –

Screw, shock absorber adjusting ring M5 5 Nm (3.7 lbf ft) –

Screws, throttle grip M5 3 Nm (2.2 lbf ft) –

KTM PowerPack attachment M6 10 Nm (7.4 lbf ft) –

Remaining nuts, chassis M6 10 Nm (7.4 lbf ft) –

Remaining screws, chassis M6 10 Nm (7.4 lbf ft) –

Screw, front brake disc M6 14 Nm (10.3 lbf ft) Loctite

243™

Screw, radiator bracket M6 7 Nm (5.2 lbf ft) –

Screw, rear brake disc M6 14 Nm (10.3 lbf ft) Loctite

243™

KTM PowerPack attachment M8 15 Nm (11.1 lbf ft) Loctite

243™

Nut, rear sprocket screw M8 35 Nm (25.8 lbf ft) Loctite

2701™

Nut, rim lock M8 10 Nm (7.4 lbf ft) –

Remaining nuts, chassis M8 25 Nm (18.4 lbf ft) –

Remaining screws, chassis M8 25 Nm (18.4 lbf ft) –

Screw of rear brake caliper M8 25 Nm (18.4 lbf ft) Loctite

243™

Screw, bottom triple clamp M8 18 Nm (13.3 lbf ft) –

Screw, chain sliding piece M8 15 Nm (11.1 lbf ft) –

Screw, fork stub M8 15 Nm (11.1 lbf ft) –

Screw, front brake caliper M8 25 Nm (18.4 lbf ft) Loctite

243™

Screw, handlebar clamp M8 20 Nm (14.8 lbf ft) –

Screw, side stand attachment M8 25 Nm (18.4 lbf ft) Loctite

2701™

Screw, subframe M8 30 Nm (22.1 lbf ft) Loctite

243™

Screw, top steering stem M8 17 Nm (12.5 lbf ft) Loctite

243™

Screw, top triple clamp M8 22 Nm (16.2 lbf ft) –

Motor bracket screw M10 60 Nm (44.3 lbf ft) –

Remaining nuts, chassis M10 45 Nm (33.2 lbf ft) –

Remaining screws, chassis M10 45 Nm (33.2 lbf ft) –

Screw, cross bar M10 45 Nm (33.2 lbf ft) –

Screw, footrest bracket M10 45 Nm (33.2 lbf ft) Loctite

243™

Screw, handlebar support M10 40 Nm (29.5 lbf ft) Loctite

243™

Screw, motor guard M10 30 Nm (22.1 lbf ft) –

Screw, upper subframe M10 45 Nm (33.2 lbf ft) Loctite

243™

Screw, bottom shock absorber M12 80 Nm (59 lbf ft) Loctite

2701™

Screw, top shock absorber M12 80 Nm (59 lbf ft) Loctite

2701™

Nut, swingarm pivot M14x1.5 75 Nm (55.3 lbf ft) –

Nut, rear wheel spindle M20x1.5 80 Nm (59 lbf ft) –

Screw, front wheel spindle M20x1.5 35 Nm (25.8 lbf ft) –

Screw, top steering head M20x1.5 12 Nm (8.9 lbf ft) –
