KTM Freeride E-XC User Manual

14 WHEELS, TIRES 83
14.1 Removing the front wheel
Preparatory work
– Deactivate the vehicle. ( p. 37)
– Fold the seat up. ( p. 63)
– Remove the KTM PowerPack. ( p. 96)
– Mount the covering cap. ( p. 64)
– Raise the motorcycle with a lift stand. ( p. 49)
C00711-10
Main work
–
Loosen screw

by several rotations.
–
Release screws

.
–
Press on screw

to push the wheel spindle out of the axle clamp.
–
Remove screw

.
C00712-10
– Holding the front wheel, withdraw the wheel spindle. Take the front wheel out of
the fork.
Info
Do not operate the front brake lever when the front wheel is removed.
Always lay the wheel down in such a way that the brake disc is not dam-
aged.
C00734-10
–
Remove spacers

.
14.2 Installing the front wheel
Warning
Danger of accidents Reduced braking efficiency due to oil or grease on the brake discs.
– Always keep the brake discs free of oil and grease, and clean them with brake cleaner when necessary.
C00734-11
Main work
– Check the wheel bearing for damage and wear.
» If the wheel bearing is damaged or worn:
– Change the front wheel bearing.
–
Clean and grease the shaft seal rings

and contact surface

of the spacers.
Long-life grease ( p. 122)
– Insert the spacers.

KTM Freeride E-XC Specifications

General

Battery Capacity	3.9 kWh
Power Output	18 kW (24 hp)
Torque	42 Nm
Rear Suspension	WP XPLOR PDS shock absorber
Seat Height	910 mm
Weight	111 kg
Ground Clearance	340 mm
Suspension Front Travel	250 mm
Suspension Rear Travel	260 mm
Motor Type	Permanent magnet synchronous motor
Charging Time 80%	75 minutes
Charging Time 100%	Approx. 110 min
Front Suspension	WP XPLOR 43
Top Speed	80 km/h
Tire Front	80/100-21
Front Brake	260 mm disc, 2-piston floating caliper
