6 CONTROLS 23
6.1 Front brake lever
C00791-10
The front brake handle
is fitted on the right side of the handlebar.
6.2 Rear brake lever
C00678-10
(Freeride E‑SX)
The rear brake lever
is fitted on the left side of the handlebar.
C00792-10
(Freeride E‑XC)
The rear brake lever
is fitted on the left side of the handlebar.
6.3 Throttle grip
C00679-10
The throttle grip
is fitted on the right side of the handlebar.
6.4 Main switch
C00793-10
The main switch
is attached to the right side of the handlebar.
The main switch is also used as an emergency OFF switch.
Possible states
Vehicle switched off.– The vehicle is switched off in this position.
Vehicle ready for operation– The vehicle is ready for operation in this
position. The start button is active.
