When Contact Pl ate i s Closed.
• When Contact Plate Is Closed:
When th e contact plate is closed , a la rge cu r rent flow th roug h
the motor section to generate a la rge mecha n ica
l power
w hich tu rns the eng
i ne cra nkshaft.
At th is time, the pi n ion is moved forward by the screw spl i ne
for more
cont ct.
Since the pu l l-i n coi l ends a re short-ci rcu ited by the contac
t
plate, the pl u nger is hel d on
l y by the force of the holdi ng
coi l.
0011F175
(d) Return Spring (h) Operated by Lever
(A) When Key Switch i s Released:
0011F176
• When Key Switch Is Released:
When the key sw itch is rel eased , a cu rrent flows i nsta nta ne-
ously throug h the pu
l l-i n coi l i n the opposite d irection as
shown
i n F ig. Therefore, the forces of th e hold ing coi l a nd
pu
l l-in coi l are ba lanced. As a resu l t, t he pl u nger i s ret urned
by the retu rn spri ng. Si mu lta neousl y, the pi nion is dis·
engaged from the ri ng gea r, the contact plate is d iscon nected,
and the starter is prom ptl y stopped by the a rmatu re brake.
(A) Construction of Bar Glow Plug
(a) (c)
....
.
.
.
.f.l.
,
,
,
;J
( ) (d)
0011F177
2) Glow pl ug
A glow pl ug is used for each pre-combustion cha mber of the
cy
l i nder head to make sta rti ng easier.
(a)
Insulating Powder
(c) Heat Coil
(b)
Housing
(d) Metal Tube
24
KiSC issued 09, 2007 A
(
A
)
When Ke
y
Switch is On:
How i
t
works:
• W hen Key Switch is On:
Wh en the key sw itch is tu rned on, a cur rent flows from the
battery th rough the pu
l l-i n coil i n the magnet sw itch section
to the hold
i ng coi l , energizi ng the pl u nger to pu l l it i n.
At th is ti me, the pi n ion moves by the dr ive lever to engage
w ith the ri ng gea r.
0011F174
(a) Battery
(b) Starter Switch
(cl Ground
(e) Spline Tube
(fl Pinion
(gl Ring Gear
(
A
)
Starter Circui
t
(a)
(
b
)
0011F173
