Kubota D1302-B - Removing Bearing Case Bolt 2; Removing Bearing Cover; Removing Flywheel

KiSC issued 09, 2007 A


8 Removing Bearing Case Bolt 2
1) Detach the bearing case bolt 2.
( Note for reassembli ng)
• Line u p the hole on the bearing case with that on the
crankcase, then tighten bearing case bolts 2.
8 Removing Flywheel
1) Detach the flywheel bolts.
2) Remove the flywheel.
(I mportant)
• When reassembli ng, tighten the f lywheel bolts to 98.1 to
107.9 N , m (10 to 11 kgf ·m, 72.3 to 79.6 lb· f t.).
• To use a f langed bolt on the conventional f lywheel,
rework the chamfered protion of the bolt hole. (Chamfer:
C0.9 to C1.3)
If the f langed bolt is used without reworking, a clearance
will develop as shown below, resu lting in an i nsuff icient
tightening torque.
(A) Reassembling of f lywheel washer
(a) Mark
I nstall the flywheel washer
so that the mark is opposite
the flywheel surface.
C019F007
(b) Clearance
Flywheel
Model Serial Number
Tightening Torque
Remarks
D1102-B
"" 38579
63.7 to 68.6 N,m
6.5 to 7.0 kgf ,m
47 .0 to 50.6 lb. ft.
Bolt and
washer
D1302-B
"" 33413
01402-B
,..., 43733
V1502-B
,..., 20822
V1702-B
,..., 43698
V1902-B
,..., 65775
01102-B
38580 ,...,
68.6 to 73.5 N• m
7.0 to 7.5 kgf • m
50.6 to 54.2 lb. f t.
Flange bolt
D1302-B
33414
D1402-B
43734 ,...,
V1502-B
20823 ,...,
V1702·B
43699 ,...,
V1902-B
65776 =
47
(
c
)
@ Removing Bearing Cover
1) R emove the bolts.
2) Drive two MS bolts into the bearing cover and then pull
the cover out.
( Note for reassembl ing)
• Grease the oil seal, be caref ul not to peal the l ip off .
Model
Serial Number
Remark
D1102·B
38692 -
Flange bolt
(without washer)
D1302-B
33434 -
D1402·B
44173 ,...,
V1502-B
21064 ,....,
V1702-B
44933 -
V1902-B
67309 ,..,,
