KiSC issued 09, 2007 A
0
Removing Pulley
1)
Clamp the shaft with a hexagonal wrench and remove the
nut.·
2)
Remove the pulley.
3)
Remove the fan.
@
Removing Drive Side End Frame
1)
Remove the three through bolts.
2)
Remove the drive end frame.
( Note for reassembli ng)
•
Do not forget
tc;>
refit the collar and the spacer.
C,
Removing Rotor
1) Draw the rotor out.
( Note for reassembli ng)
•
To refit the rotor, thread a wi re th rough the access hole
and lif t the brush u p with it.
(d) End frame
(e)
Slip ring
(f )
Bearing
80
