KiSC issued 09, 2007 A
•
MAGNET SWITCH TYPE STARTER
0
Removing Magnet Switch
1)
Remove the connecti ng lead .
2)
Remove the set screws.
3)
Detach the magnet switch by
l
ifti ng
i
t u p wh
i l
e taki ng
care th at it d oes not contact the d ri ve lever.
f)
Removing Armature Brake
1)
Remove the end frame cap.
2)
Remove the washers.
3)
Remove the packi ng.
8
Removing End Frame
1)
R emove the t hrough bolts.
2)
R emove the end frame.
e
Removing Brush Holder
1)
D raw out the brush from the holder whi le hold
i
ng the
spring u p.
2)
Take off the brush holder.
( Note for reassembli ng)
•
Be sure not to mistake the d
i
rection a nd position of the
spring.
•
Do not contact the body with the positive brush's lead.
88
