Kubota D1302-B - Detaching Governor Spring; Removing Speed Control Plate

KiSC issued 09, 2007 A


(A) How to remove governor spring
0 Detaching Governor Spring
1) Detach the governor spring 1 and 2 from the governor
fork lever 2.
(a) Detach
on the
C019 F002
(b) Gear case
- (cl Fork lever 2
39
@ Removing Speed Control Plate
1) Remove the speed control plate and governor spring.
(Note for reassembling)
• Be careful not to drop the governor spring in the gear
case.
governor spr
i
ng
side of fork ! J
-
-
