KiSC issued 09, 2007 A
(A)
Inside view of gear case assembly
(b) 0-ring
CD
Removing Gear Case Assembly
1)
Remove the gear case.
2)
Remove the 0-ring.
(Important)
•
When reassembl ing do not forget to refit the 0-ring.
•
Apply some grease to the oil seal, and refit it carefully
so that its
l i
p
will
not peal off .
(f)
Removing Crankshaft Collar and Oil Slinger
1)
Remove the crankshaft collar, the 0-ring, oil slinger
and the crank gear collar (D1102-B, D1302·B, D1402·B
only) in that order.
( Note for reassem bling)
•
Apply oil to the 0-ring. Do not conf use assem bl ing
order.
(1)
Oil slinger
(2)
0-ring
(3) Crank shaft collar
(4) Crank gear collar
(5)
Oil slinger
(6)
0-ring
(7) Crank shaft collar
41
