KiSC issued 09, 2007 A
Q
Removing Voke
1)
)
Draw out the yoke from the d rive end frame.
(Note for reassembling)
•
Take care for yoke knock pin.
0
Removing Armature
1)
Rem ove the set bol t from the d ri ve lever.
2)
Draw out the a rmatu re from the d ri ve end frame.
3)
Detach the d rive
l
eve r.
(Important)
•
When reassembling, be sure not to mistake the installing
direction of the drive lever.
C0:!2F07-t
89
