Kubota D1302-B - Removing Water Pump; Disassembling the Water Pump; Removing Water Pump Shaft and Bearing Assembly

KiSC issued 09, 2007 A


@ Removing Water Pump
1) Detach th e water pu m p from the gear case.
Disassembling the Water Pump
( 1) Removing Fan Pulley
1) Straig hten the l ock washer.
2) R emove the fa n pu lley.
(2) Removing Water Pump Shaft and
Bearing Assembly
1) Remove th e snap pin. (Snap pin type only)
2) R emove the water pu m p shaft fla nge.
3) R emove the i m pel ler.
4) Dr i ve out the water pu m p shaft a nd bea ri ng assembl y
from the
i m pel l er sid e of the water pu m p.
(I mporta nt)
• When reassembl i ng, replace the water pu mp shaft a nd
beari ng assembly by new one.
(1) Insert surely (Snap pin type only)
(2) Snap pin (Special) (Snap pin type only)
(3) Water pump shaft and bearing assembly
