KiSC issued 09, 2007 A
2.DISASSEMBLY AND REASSEMBLY
•
ATTENTION: When reassembling, replace all the 0-ring and gaskets by new ones.
0
Removing Cylinder Head Cover
1)
Remove cap nuts from the cylinder head cover.
2)
Remove the cyl inder head cover and the gasket from the
cyl inder head.
( Note for reassembl ing)
•
Tighten the cap nu ts to 6.9 to 8.8 N•m. (0.7 to 0.9
kgf·m,
5.1
to
6.5 lb.ft.)
•
Be caref ul to ref it the breather oil shield in the right
direction.
8
Removing Alternator and Fan Belt
1)
Remove the alternator.
2)
Detach the fan bel t.
( Note for reassembling)
•
Fan belt tension
The belt should def lect approx. 7 to
9
mm (0.2756 to
0.3543
in.) when the center of belt is depressed with a
finger pressu re of
58.8
to
68.6
N.
(6
to
7
kgf .,
13.2
to
15.4 l b.)
C, Removing Rocker Arm and Push Rod
1)
Detach the rocker arm.
2)
Remove the push-rods.
( Note for reassembl ing)
•
I
nsert the push-rods into the tappets secu rely.
•
Tigh ten the rocker arm bracket mou nting nuts to 23.5 to
27.5
N-m.
(2.4 to 2.8 kgf ,m, 17.4 to 20.3
l
b.f t.)
35
