Kubota G2160 User Manual

5-S14
G2160, WSM
STEERING
3. SERVICING SPECIFICATIONS
W1013874
4. TIGHTENING TORQUES
Tightening torques of screws, bolts and nuts on the table below are especially specified.
(For general use screws, bolts and nuts : See page G-9.)
W1012161
Item Factory Specification Allowable Limit
Steering Wheel Play Less than 15 mm
Less than 0.59 in.
–
Throttle Lever Operating Force 30 to 50 N
3.1 to 5.1 kgf
66 to 110 lbs
–
Difference in Steering Force of Steering Wheel between Right
and Left
Less than 25 % –
Steering Load Engine stopped
(Without power
assisting)
Less than 150 N
Less than 15 kgf
Less than 33 lbs
–
Engine started
(With power
assisting)
Less than 30 N
Less than 3 kgf
Less than 6.6 lbs
–
Turning Torque
(Steering Mechanical System)
Without power
assisting
Less than 2.0 N·m
Less than 0.20 kgf·m
Less than 1.4 ft-lbs
–
Turning Torque
(Power Steering Gear Case)
Without power
assisting
Less than 3.6 N·m
Less than 0.37 kgf·m
Less than 2.7 ft-lbs
–
Item N·m kgf·m ft-lbs
Steering wheel mounting nut
Rod end mounting nut
Lock nut
Power steering gear case mounting screw
19.6 to 24.5
108.8 to 130.3
62.7 to 72.5
40.2 to 47.0
2.0 to 2.5
11.1 to 13.3
6.4 to 7.4
4.1 to 4.8
14.5 to 18.1
80.3 to 96.2
46.3 to 53.5
29.7 to 34.7
KiSC issued 11, 2006 A
