1-S11
G2160, WSM
ENGINE
3. TIGHTENING TORQUES
Tightening torques of screws, bolts and nuts on the table below are especially specified.
(For general use screws, bolts and nuts : See page G-9.)
• For * marked screws, bolts and nuts on the table, apply engine oil to their threads and seats before
tightening.
• The letter “M” in Size x Pitch means that the screw, bolt or nut dimension stands for metric. The size is
the nominal outside diameter in mm of the threads. The pitch is the nominal distance in mm between two
threads.
W1013236
Item Size x Pitch N·m kgf·m ft-lbs
Starter M terminal nut
Alternator B terminal nut
Glow plug terminal mounting nut
Universal joint mounting screw
Engine mounting nut
Cylinder head bolt
* Cylinder head cover cap nut
Injection pipe retaining nut
Nozzle holder assembly
Overflow pipe assembly retaining nut
(nozzle)
Glow plug
* Rocker arm bracket nut
* Fan drive pulley retaining screw
* Idle gear shaft mounting screw
* Connecting rod screw
* Flywheel bolt
* Main bearing case screw 2
* Main bearing case screw 1
Oil pressure switch
Nozzle holder
M6 × 1.0
M6 × 1.0
M8 × 1.25
M8 × 1.25
M8 × 1.25
M6 × 1.0
M12 × 1.5
M20 × 1.5
M12 × 1.5
M8 × 1.0
M6 × 1.0
M12 × 1.5
M6 × 1.0
M7 × 0.75
M10 × 1.25
M7 × 1.0
M6 × 1.0
PT 1/8
9.8 to 13.7
7.8 to 9.3
1.0 to 1.8
23.5 to 27.5
23.5 to 27.5
37.2 to 42.1
3.9 to 5.9
24.5 to 34.3
49.0 to 68.6
19.6 to 24.5
7.8 to 14.7
9.8 to 11.3
117.6 to 127.4
9.8 to 11.3
26.5 to 30.4
53.9 to 58.8
26.5 to 30.4
12.7 to 15.7
14.7 to 19.6
34.3 to 39.2
1.0 to 1.4
0.80 to 0.95
0.10 to 0.18
2.4 to 2.8
2.4 to 2.8
3.8 to 4.3
0.4 to 0.6
2.5 to 3.5
5.0 to 7.0
2.0 to 2.5
0.8 to 1.5
1.00 to 1.15
12.0 to 13.0
1.00 to 1.15
2.7 to 3.1
5.5 to 6.0
2.7 to 3.1
1.3 to 1.6
1.5 to 2.0
3.5 to 4.0
7.2 to 10.1
5.8 to 6.9
0.74 to 1.33
17.4 to 20.3
17.4 to 20.3
28.0 to 31.7
2.9 to 4.3
18.1 to 25.3
36.2 to 50.6
14.5 to 18.1
5.8 to 10.8
7.2 to 8.3
86.8 to 94.0
7.2 to 8.3
19.5 to 22.4
39.8 to 43.4
19.5 to 22.4
9.4 to 11.6
10.8 to 14.5
25.3 to 28.9
To Next Page
