G-32
G2160, WSM
G GENERAL
Replacing Bulbs
(A) Replacing the head light bulb
1. Open hood.
2. Turn bulb socket to remove socket from headlight housing.
3. Push bulb down and turn one quarter turn to remove bulb from
the socket.
4. Install new bulb to the socket.
5. Install the socket in housing.
6. Close hood.
(B) Replacing the indicator light bulb
1. Open hood.
2. Turn bad bulb socket to the left.
3. Pull bulb from the socket.
4. Push new bulb into the socket.
5. Install the socket.
6. Close hood.
W1047730
Head light bulb Capacity
1.04A / 12.8 Rated
voltage
Indicator light bulb Capacity
0.27A / 14.0 Rated
voltage
