G-40
G2160, WSM
G GENERAL
• The following special tool is not provided, so make it referring to the figure.
Steering Wheel Puller Adaptor
Application: Use for removing the steering wheel with steering wheel
A 22 mm (0.87 in.) F 116 mm (4.57 in.)
B 64 mm (2.52 in.) G 5 mm (0.20 in.)
C 11 mm (0.43 in.) H 9.5 mm (0.38 in.)
D 32 mm (1.26 in.) I 3 mm (0.12 in.)
E 20 mm (0.79 in.) J 5 mm (0.20 in.)
