Kubota G2160 User Manual

1-S6
G2160, WSM
ENGINE
Valve Spring
W1014987
Rocker Arm
W1015094
Push Rod
W1015197
Tappet
W1013874
Camshaft
W1016577
Item Factory Specification Allowable Limit
Free Length 31.3 to 31.8 mm
1.232 to 1.252 in.
28.4 mm
1.118 in.
Setting Load / Setting Length 64.7 N / 27.0 mm
6.6 kgf / 27.0 mm
14.6 lbs / 1.063 in.
54.9 N / 27.0 mm
5.6 kgf / 27.0 mm
12.3 lbs / 1.063 in.
Tilt – 1.2 mm
0.047 in.
Clearance between Rocker Arm Shaft and Rocker Arm
Rocker Arm Shaft O.D.
Rocker Arm I.D.
0.016 to 0.045 mm
0.00063 to 0.00177 in.
10.473 to 10.484 mm
0.41232 to 0.41276 in.
10.500 to 10.518 mm
0.41339 to 0.41410 in.
0.15 mm
0.0059 in.
–
–
Push Rod Runout – 0.50 mm
0.0196 in.
Clearance between Tappet and Guide
Tappet O.D.
Tappet Guide I.D.
0.016 to 0.052 mm
0.00063 to 0.00205 in.
17.966 to 17.984 mm
0.70732 to 0.70803 in.
18.000 to 18.018 mm
0.70866 to 0.70937 in.
0.10 mm
0.0039 in.
–
–
Camshaft Side Clearance 0.15 to 0.31 mm
0.0059 to 0.0122 in.
0.50 mm
0.0197 in.
Camshaft Runout – 0.02 mm
0.0008 in.
Cam Height of Intake and Exhaust 26.88 mm
1.0583 in.
26.83 mm
1.0563 in.
Oil Clearance of Camshaft
Camshaft Journal O.D.
Camshaft Bearing I.D.
0.050 to 0.091 mm
0.00197 to 0.00358 in.
32.934 to 32.950 mm
1.29661 to 1.29724 in.
33.000 to 33.025 mm
1.29921 to 1.30020 in.
0.15 mm
0.0059 in.
–
–
KiSC issued 11, 2006 A
