GENERATOR
GL6000A-AU-B, GL6000D-AU-B,GL9000A-AU-B, GL9000D-AU-B, WSM
2-M4
3. EMERGENCY RELAY CIRCUIT (GL6000A-AU-B,
GL9000A-AU-B)
[1] GENERAL
This is an automatic engine stopping device. This
device senses any abnormal situation on engine and
related parts, such as oil pressure, water temperature, or
fan belt broken, occurring during engine operation, and
activates the stop solenoid to cut off fuel to the fuel
injection pump and stop the engine.This relay has two
independent timer functions, a start relay and a stop
relay.
The start relay does not activate this relay for a
specified time period after the engine has started.
• When this device stops the engine, it may be that
some minor damages to the engine has
occurred.
To limit engine damage as much as possible,
please do not make the faulty assumption that it
is a perfectly safety device.
9Y1211607GRM0005US0
(1) Emergency Relay
To Next Page
