INFORMATION
GL6000A-AU-B, GL6000D-AU-B,GL9000A-AU-B, GL9000D-AU-B, WSM
I-13
3. SPECIFICATIONS
*Conversion Formula: HP = 0.746 kW, PS = 0.7355 kW
Model GL6000A-AU-B GL6000D-AU-B
Generator
Design Salient-pole, revolving-field AC generator (AVR system with separate and self-excitation brush)
Frequency 50 Hz
Rated output (COP)
5.5 kVA
5.5 kW
Rated voltage 240 V
Rated amperage 22.9 A
Phase and wire 1 - 2 ϕ - W
Power factor 100 %
Number of poles 2
Insulation Rotor coil: Class F, Stator coil: Class B
Voltage regulation 5 % (No load to full load)
Total harmonic distortion 8 % (No load), 22 % (Full load)
Type of coupling Direct coupled
Engine
Model Z482
Design Vertical, water-cooled, 4-cycle diesel engine
Number of cylinders 2
Bore × stroke ϕ 67 × 68 mm (2.6 × 2.7 in.)
Displacement 0.479 L (29.2 cu.in.)
Engine speed 3000 min
-1
(rpm)
Lubricating oil API service class CF or higher
Oil capacity 2.2 L (0.58 U.S.gals)
Coolant capacity 3.7 L (0.98 U.S.gals)
Set
Fuel Diesel fuel No. 2 (ASTM D975)
Fuel consumption (at full load) 2.4 L/h (0.63 U.S.gals/h)
Fuel tank capacity 28 L (7.4 U.S.gals)
Continuous operating hours 12 hrs
Battery (V × Ah/5Hr) 44B19R (12 V × 27 Ah/5Hr)
Starting system Electric
Dimension (L × W × H) 1066 mm × 618 mm × 698 mm (41.97 in. × 24.3 in. × 27.5 in.)
Approx net weight 235 kg (518 lbs.)
Controller Analog Digital - DSE4520
Receptacles 2 × 15A (IP56 rated, auto switched)
Electrical protection 25A MCB (2 Pole), 16A RCBO 30mA (2 Pole) × 2, MEN link at alternator.
Shutdown system
In case of abnormal: Oil pressure, water temperature
Emergency stop button, engine room door opened
– Under/Over voltage and frequency
