Kubota GL9000D-AU-B User Manual

GENERAL
GL6000A-AU-B, GL6000D-AU-B,GL9000A-AU-B, GL9000D-AU-B, WSM
G-12
5. TIGHTENING TORQUES
Tighten screws, bolts and nuts whose tightening torques are not specified in this Workshop Manual
according to the table below.
9Y1211607GEG0005US0
[1] GENERAL USE SCREWS, BOLT AND NUTS
9Y1211607GEG0006US0
[2] STUD BOLTS
9Y1211607GEG0007US0
Indication on top of bolt
No-grade or 4T 7T
Material of opponent part Ordinariness Aluminum Ordinariness Aluminum
Unit N·m kgf·m lbf·ft N·m kgf·m lbf·ft N·m kgf·m lbf·ft N·m kgf·m lbf·ft
M4
(4.0 mm, 0.16 in.)
0.98
to
2.9
0.10
to
0.30
0.73
to
2.1
–––––––––
M5
(5.0 mm, 0.20 in.)
2.0
to
3.9
0.20
to
0.40
1.5
to
2.8
–––––––––
M6
(6.0 mm, 0.24 in.)
7.9
to
9.3
0.80
to
0.95
5.8
to
6.8
7.9
to
8.8
0.80
to
0.90
5.8
to
6.5
9.81
to
11.2
1.00
to
1.15
7.24
to
8.31
7.9
to
8.8
0.80
to
0.90
5.8
to
6.5
M8
(8.0 mm, 0.31 in.)
18
to
20
1.8
to
2.1
13
to
15
17
to
19
1.7
to
2.0
13
to
14
24
to
27
2.4
to
2.8
18
to
20
18
to
20
1.8
to
2.1
13
to
15
M10
(
10 mm, 0.39 in.)
40
to
45
4.0
to
4.6
29
to
33
32
to
34
3.2
to
3.5
24
to
25
48
to
55
4.9
to
5.7
36
to
41
40
to
44
4.0
to
4.5
29
to
32
M12
(12 mm, 0.47 in.)
63
to
72
6.4
to
7.4
47
to
53
–––
78
to
90
7.9
to
9.2
58
to
66
63
to
72
6.4
to
7.4
47
to
53
M14
(14 mm, 0.55 in.)
108
to
125
11.0
to
12.8
79.6
to
92.5
–––
124
to
147
12.6
to
15.0
91.2
to
108
–––
Material of opponent part Ordinariness Aluminum
Unit N·m kgf·m lbf·ft N·m kgf·m lbf·ft
M8
(8.0 mm, 0.31 in.)
12
to
15
1.2
to
1.6
8.7
to
11
8.9
to
11
0.90
to
1.2
6.5
to
8.6
M10
(10 mm, 0.39 in.)
25
to
31
2.5
to
3.2
18
to
23
20
to
25
2.0
to
2.6
15
to
18
