GENERATOR
GL6000A-AU-B, GL6000D-AU-B,GL9000A-AU-B, GL9000D-AU-B, WSM
2-S10
3. TIGHTENING TORQUES
Tightening torques of screws, bolts and nuts on the table below are especially specified.
(For general use screws, bolts and nuts: See page "5. TIGHTENING TORQUES" on page G-12.)
9Y1211607GRS0010US0
[1] TIGHTENING TORQUES FOR SPECIAL USE SCREWS, BOLTS
AND NUTS
• In removing and applying the screws, bolts and nuts marked with " * ", pneumatic wrench or similar
pneumatic tool, if employed, must be used with enough care not to get them seized.
• For " * " marked screws, bolts and nuts on the table, apply engine oil to their threads and seats before
tightening.
[GL6000A-AU-B, GL6000D-AU-B]
[GL9000A-AU-B, GL9000D-AU-B]
9Y1211607GRS0011US0
Item N·m kgf·m lbf·ft
Stator mounting screw 6 to 8 0.6 to 0.9 5 to 6
Rotor assembly mounting screw 35 to 44 3.5 to 4.5 26 to 32
PTO shaft mounting screw 48 to 55 4.9 to 5.7 36 to 41
Engine mounting nut 20 to 27 2.0 to 2.8 15 to 20
Generator mounting nut 20 to 27 2.0 to 2.8 15 to 20
Item N·m kgf·m lbf·ft
Stator mounting screw 19 to 21 1.9 to 2.2 14 to 15
Rotor assembly mounting screw 20 to 27 2.0 to 2.8 15 to 20
PTO shaft mounting screw 20 to 27 2.0 to 2.8 15 to 20
Engine mounting nut 54 to 68 5.5 to 7.0 40 to 50
Generator mounting nut 54 to 68 5.5 to 7.0 40 to 50
To Next Page
