PERIODIC SERVICE80
BChecking Intake Air Line
1. Check to see that hoses and hose clamps are tight and
not damaged.
2. If hoses and clamps are found worn or damaged,
replace or repair them at once.
BChecking Power Steering Line
1. Check to see that all lines and hose clamps are tight
and not damaged.
2. If hoses and clamps are found worn or damaged,
replace or repair them at once.
BAdjusting Toe-in
1. Park tractor on a flat place.
2. Turn steering wheel so front wheels are in the straight
ahead position.
3. Lower the implement, lock the park brake and stop the
engine.
4. Measure distance between tire beads at front of tire, at
hub height.
5. Measure distance between tire beads at rear of tire, at
hub height.
6. Front distance should be shorter than rear distance.
If not, adjust tie rod length.
(1) Hose
(2) Hose clamps
(1) Power steering pressure hoses
Proper toe-in
4WD 2 to 8 mm (0.08 to 0.31 in.)
2WD 1 to 5 mm (0.04 to 0.2 in.)
