Kubota M96SDTM User Manual

83PERIODIC SERVICE
BCleaning Water Separator
[M96S]
This job should not be done in the field, but in a clean
place.
1. Close the fuel cock.
2. Unscrew the retainer ring and remove the cup, and
rinse the inside with kerosene.
3. Take out the element and dip it in the kerosene to
rinse.
4. After cleaning, reassemble the water separator,
keeping out dust and dirt.
5. Bleed the fuel system.
(See "Bleeding Fuel System" in "SERVICE AS
REQUIRED" in "PERIODIC SERVICE" section.)
[M108S]
This job should not be done in the field, but in a clean
place.
1. Close the fuel cock.
2. Unscrew the cup and remove it, then rinse the inside
with kerosene.
3. Take out the element and dip it in the kerosene to
rinse.
4. After cleaning, reassemble the water separator,
keeping out dust and dirt.
5. Bleed the fuel system.
(See "SERVICE AS REQUIRED" in "PERIODIC
SERVICE" section.)
(1) Fuel cock
(2) Retainer ring
(3) Cup
(A) "CLOSE"
(1) O ring
(2) Element
(3) Spring
(4) Red float
(5) Cup
(6) Retainer ring
(1) Fuel cock
(2) Cup
(A) "CLOSE"
(1) O ring
(2) Element
(3) Element cup
(4) Red float
(5) Cup
(6) Drain plug
